RF300 system planning
4.3 Relationship between the volume of data and the transponder speed
SIMATIC RF300
4-28 System Manual, Release 04/2006, J31069 D0166-U001-A2-7618
Figure 4-20 Relationship between speed and volume of data (reading/writing from FRAM) in dynamic
operation when using the RF350R with ANT1 and RF360T
Note:
The curves for the RF320T are valid for reading/writing to the EEPROM memory area of the
RF340T, RF350T and RF360T transponders.
Note:
The antennas ANT18 and ANT30 only have small transmission windows. They are therefore
only suitable for dynamic operation to a limited extent. It was not necessary to show
corresponding curves.
