Table 4-7 Reduction of field data by metal (in %): Transponder and RF350R with ANT18
Mounting the antenna
Transponder Without metal flush-mounted
in metal
(10 mm surround;
10 mm deep)
RF320T
Without metal 100 100
On metal; distance 20 mm 100 100
Flush-mounted in metal; distance all-round
20 mm
80 80
RF340T
Without metal 100 100
on metal 80 80
Flush-mounted in metal;
distance all-round 20 mm
70 70
RF350T
Without metal 1) 1)
on metal 1) 1)
Flush-mounted in metal;
distance all-round 20 mm
1) 1)
RF360T
Without metal 1) 1)
On metal; distance 20 mm 1) 1)
Flush-mounted in metal;
distance all-round 20 mm
1) 1)
1) combination not permitted
