RF300 system planning
4.4 Installation guidelines
SIMATIC RF300
4-34 System Manual, Release 04/2006, J31069 D0166-U001-A2-7618
Reduction of field data: Transponder and RF340R reader
Table 4-5 Reduction of field data by metal (in %): Transponder and RF340R
Reader RF340R
Transponder Without metal on metal flush-mounted
in metal
(20 mm surround)
RF320T
Without metal 100 95 80
On metal; distance 20 mm 100 90 75
Flush-mounted in metal; distance
all-round 20 mm
80 70 60
RF340T
Without metal 100 95 85
on metal 80 80 70
Flush-mounted in metal;
distance all-round 20 mm
70 70 70
RF350T
Without metal 100 95 80
on metal 70 65 65
Flush-mounted in metal;
distance all-round 20 mm
60 60 60
RF360T
Without metal 100 95 85
On metal; distance 20 mm 90 90 75
Flush-mounted in metal;
distance all-round 20 mm
70 60 60
