Antennas
6.2 SIMATIC RF615A
SIMATIC RF600
236 System Manual, 06/2019, J31069-D0171-U001-A22-7618
C
Cable designa-
t
tion
A
Article number
L
Length [m]
C
Cable loss [dB]
B
Bending radius
[
[mm]
Antenna cable
(suitable for drag
chains)
6GT2815-2BN15 15 4 45
1) 2)
Antenna cable 6GT2815-0BN20 20 4 77
Antenna cable
6GT2815-0BN40
40
5
77
1
)
Permissible minimum bending radius with one-time bending. 28 mm
2
)
With cables capable of being used in drag chains, 100,000 bending cycles at a bending radius of
100 mm and a bend of ± 180° or 3 million torsion cycles with a bend of ± 180° on a cable length of
1 m are permitted.
6
6.2.5 Antenna parameter assignment
Depending on the country or region in which the antenna is being operated, it is subject to
regional limitations with respect to the radiated power.
Limitations in the EU, EFTA, or Turkey
Note
L
Limitation of the radiated power according to EN
302 208 V1.4.1 (ETSI)
R
F600 systems that are put into operation in the EU, EFTA or Turkey must not exceed the
f
ollowing radiated power with an RF615A antenna:
x 500 mW ERP (or 27 dBm ERP)
Converted into EIRP: 820 mW EIRP (or 29 dBm EIRP)
Make the following settings to ensure that the maximum permitted radiated power of the
antenna is not exceeded:
Ⴠ Antenna gain: -5 dBi
Ⴠ Radiated power: ื 340 mW ERP (or 25.35 dBm ERP)
Converted into EIRP: ื 560 mW EIRP (or 27.5 dBm EIRP)
Ⴠ Use of cable loss associated with the antenna cable.
