RF600 system planning
4.4 Minimum distances and maximum ranges
SIMATIC RF600
System Manual, 06/2019, J31069-D0171-U001-A22-7618
63
Table 4- 7 Read range of the transponders IV (all ranges in meters [m])
S
SIMATIC RF620T
1
1)
SIMATIC RF625T
2)
SIMATIC RF630T
2)
SIMATIC RF640T
2)
SIMATIC RF610R
S
SIMATIC RF615R
with internal antenna 1.0 0.3 0.3 0.4
SIMATIC RF615R
with RF615A 1.0 0.1 0.1 0.2
with RF620A
1.2
0.1
0.2
0.2
with RF640A 4.0 0.3 0.4 0.7
with RF642A
4.0
1.0
0.5
1.4
with RF650A
3.5
0.2
0.4
0.7
with RF660A
4.0
0.8
1.0
1.2
with RF680A
4.0
0.2
0.5
1.2
SIMATIC RF650R
with RF615A 1.8 0.3 0.4 0.6
with RF620A
1.8
0.4
0.4
0.7
with RF640A
5.0
1.0
1.0
1.8
with RF642A
7.0
1.8
2.0
2.5
with RF650A
4.0
1.0
0.9
2.0
with RF660A
6.0
1.4
1.8
2.0
with RF680A
4.0
0.8
0.9
2.0
SIMATIC RF685R
with internal antenna 7.0 2.0 2.0 3.5
SIMATIC RF680R
S
SIMATIC RF685R
with RF615A 2.5 0.5 0.5 0.8
with RF620A
2.5
0.5
0.5
1.0
with RF640A
6.0
1.4
1.4
2.5
with RF642A
7.0
1.8
2.0
4.0
with RF650A
5.0
1.4
1.2
2.5
with RF660A
6.0
1.4
1.8
3.0
with RF680A
6.0
1.2
1.2
3.0
1
)
Mounting on a non-metallic surface. Mounting on metal is only permitted in combination with a spacer.
2
)
Mounting on metal Mounting surface with a minimum diameter of 150 mm, for the RF630T 300 mm.
