5.3 Diagnostics alarms
Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
Manual, 09/2016, A5E36647959-AB
45
5.3
Diagnostics alarms
A diagnostics alarm is generated and the ERROR LED flashes for each diagnostics event on
the module. The diagnostics alarms can be read out in the diagnostics buffer of the CPU, for
example. You can evaluate the error codes with the user program.
If the module is operated distributed with PROFIBUS DP in an ET 200MP system, you have
the option to read out diagnostics data with the instruction RDREC or RD_REC using data
record 0 and 1. The structure of the data records is available on the Internet in the "Manual
for interface module IM 155-5 DP ST (6ES7155-5BA00-0AB0)".
Table 5- 5 Diagnostics alarms, their meaning and corrective measures
Diagnostics alarm
Error code
Meaning
Remedy
Wire break 6
H
Impedance of encoder circuit too
high
Use a different encoder type or modify the
wiring, for example, using cables with
larger cross-section
Wire break between the module and
sensor
Connect the cable
Channel not connected (open)
• Disable diagnostics
• Connect the channel
Overflow
7
H
Measuring range violated
Check the measuring range
Underflow
8
H
Measuring range violated
Check the measuring range
Parameter assignment
error
10
H
• The module cannot evaluate
parameters for the channel
• Incorrect parameter assignment.
Correct the parameter assignment
Load voltage missing 11
H
Supply voltage L+ of the module is
missing
Connect supply voltage L+ to module
Reference channel
error
15
H
Invalid reference temperature for the
used TC channel with compensation
Check compensation with reference
channel parameterization or thermoresis-
tor. Check communication to the mod-
ule/station for the compensation with data
record.
Diagnostics alarms with value status (QI)
If you configure the module with value status (QI), the module always checks all errors even
if the respective diagnostics is not enabled. But the module cancels the inspection as soon
as it detects the first error, regardless if the respective diagnostics has been enabled or not.
The result may be that enabled diagnostics may not be displayed.
Example:
You have enabled "Underflow" diagnostics, but the module detects the previous
"Wire break" diagnostics and aborts after this error message. The "Underflow" diagnostics is
not detected.
Recommendation:
To ensure that all errors are subjected to the diagnostics, select all check
boxes under "Diagnostics".
