Representation of analog values
C.4 Representation of analog values for thermocouples
Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
80 Manual, 09/2016, A5E36647959-AB
C.4
Representation of analog values for thermocouples
The following tables list the decimal and hexadecimal values (codes) of the supported
thermocouples.
Table C- 16 Thermocouple type B
Type B in
°C
Values
Type B in
°F
Values
Type B in
K
Values
Range
dec.
hex.
dec.
hex.
dec.
hex.
> 2070.0
32767
7FFF
> 3276.6
32767
7FFF
> 2343.2
32767
7FFF
Overflow
2070.0
:
1820.1
20700
:
18201
50DC
:
4719
3276.6
:
2786.6
32766
:
27866
7FFE
:
6CDA
2343.2
:
2093.3
23432
:
20933
5B88
:
51C5
Overrange
1820.0
:
250.0
18200
:
2500
4718
:
09C4
2786.5
:
482.0
27865
:
4820
6CD9
:
12D4
2093.2
:
523.2
20932
:
5232
51C4
:
1470
Nominal
range
249.9
:
0.0
2499
:
0
09C3
:
0
481.9
:
32.0
4819
:
320
12D3
:
0140
523.1
:
273.2
5231
:
2732
1469
:
0AAC
Underrange
< 0.0
-32768
8000
< 32.0
-32768
8000
< 273.2
32768
8000
Underflow
Table C- 17 Thermocouple Type C
Type C
in °C
Values
Type C
in °F
Values
Type C
in °K
Values
Range
dec.
hex.
dec.
hex.
dec.
hex.
> 2500.0
32767
7FFF
> 3276.6
32767
7FFF
> 2773.2
32767
7FFF
Overflow
2500.0
:
2300.1
25000
:
23001
61A8
:
59D9
3276.6
:
2786.6
32766
:
27866
7FFE
:
6CDA
2773.2
:
2573.3
27732
:
25733
6C54
:
6485
Overrange
2300.0
:
0.0
23000
:
0
59D8
:
0000
2786.5
:
32.0
27865
:
320
6CD9
:
0140
2573.2
:
273.2
25732
:
2732
6484
:
0AAC
Nominal
range
-0.1
:
-120.0
-1
:
-1200
FFFF
:
FB50
31.9
:
-184.0
319
:
-1840
013F
:
F8D0
273.1
:
153.2
2731
:
1532
0AAB
:
05FC
Underrange
< -120.0
-32768
8000
< -184.0
-32768
8000
< 153.2
32768
8000
Underflow
