Siemens SIMATIC S7-1500T User Manual

Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
46 Manual, 09/2016, A5E36647959-AB
Technical specifications
6
Technical specifications of the AI 8xU/R/RTD/TC HF
6ES7531-7PF00-0AB0
General information
Product type designation
AI 8xU/R/RTD/TC HF
Hardware functional status
FS01
Firmware version
V1.1.0
•
FW update possible
Yes
Product function
I&M data
Yes; I&M0 to I&M3
Measuring range scalable
Yes
Measured values scalable
No
Measuring range adjustment
No
Engineering with
STEP 7 TIA Portal can be configured/integrated
as of version
V14 / -
STEP 7 can be configured/integrated as of version
V5.5 SP3 / -
PROFIBUS as of GSD version/GSD revision
V1.0 / V5.1
PROFINET as of GSD version/GSD revision
V2.3 / -
Operating mode
Oversampling
No
MSI
Yes
CiR Configuration in RUN
Configuration in RUN possible
Yes
Calibration in RUN possible
Yes
Supply voltage
Rated value (DC)
24 V
Valid range, low limit (DC)
20.4 V
Valid range, high limit (DC)
28.8 V
Reverse polarity protection
Yes
Input current
Current consumption, max.
55 mA; with 24 V DC supply
Power
Power consumption from the backplane bus
0.85 W
Power loss
Power loss, typ.
1.9 W
