Siemens SIMATIC S7-1500T User Manual

Technical specifications
Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
Manual, 09/2016, A5E36647959-AB
47
6ES7531-7PF00-0AB0
Analog inputs
Number of analog inputs
8; plus an additional RTD (reference) channel
•
For voltage measurement
8; plus an additional RTD (reference) channel
•
For resistance/resistance thermometer meas-
urement
8; plus an additional RTD (reference) channel
•
for thermocouple measurement
8; plus an additional RTD (reference) channel
Permissible input voltage for voltage input (d
e-
struction limit), max.
20 V
Technical unit for temperature measurement, can
be set
Yes; °C / °F / K
Input ranges (rated values), voltages
-1 to +1 V
Yes
Input resistance (-1 to +1 V)
10 MΩ
-25 mV to +25 mV
Yes
Input resistance (-25 mV to +25 mV)
10 MΩ
-250 to +250 mV
Yes
Input resistance (-250 to +250 mV)
10 MΩ
-50 mV to +50 mV
Yes
Input resistance (-50 mV to +50 mV)
10 MΩ
-500 mV to +500 mV
Yes
Input resistance (-500 mV to +500 mV)
10 MΩ
-80 mV to +80 mV
Yes
Input resistance (-80 mV to +80 mV)
10 MΩ
Input ranges (rated values), thermocouples
Type B
Yes
Input resistance (type B)
10 MΩ
Type C
Yes
Input resistance (Type C)
10 MΩ
Type E
Yes
Input resistance (type E)
10 MΩ
Type J
Yes
Input resistance (type J)
10 MΩ
Type K
Yes
Input resistance (type K)
10 MΩ
Type N
Yes
Input resistance (type N)
10 MΩ
Type R
Yes
Input resistance (type R)
10 MΩ
Type S
Yes
Input resistance (type S)
10 MΩ
Type T
Yes
Input resistance (type T)
10 MΩ
Type TXK/TXK(L) according to GOST
Yes
