Technical specifications
Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
50 Manual, 09/2016, A5E36647959-AB
6ES7531-7PF00-0AB0
Thermocouple (TC)
Temperature compensation
Configurable
Yes
Internal temperature compensation
Yes
External temperature compensation via RTD
Yes
Compensation for 0 °C reference point tem-
perature
Yes, fixed value can be set
Reference channel of the module
Yes; 9th channel that can be used regardless of
the parameterization of the other channels than
as the genuine 9th RTD channel or for compen-
sation for TC measurement
Cable length
shielded, max.
800 m; with U; 200 m with R/RTD/TC
Analog value generation for the inputs
Integration and conversion time/resolution per
channel
Resolution with overrange (bit including sign),
max.
16 bit
Configurable integration time
Yes
Integration time (ms)
Fast mode: 2.5 / 16.67 / 20 / 100 ms; standard
mode: 7.5 / 50 / 60 / 300 ms
Basic convers
ion time, including integration time
(ms)
Fast mode: 4 / 18 / 22 / 102 ms; standard mode:
9 / 52 / 62 / 302 ms
Additional conversion time for wire break moni-
toring
Thermocouples. 150 Ohm, 300 Ohm, 600 Ohm,
Cu10, Cu50, Cu100, Ni10, Ni50, Ni100, Ni120,
Ni200, Pt10, Pt50, Pt100, Pt200: 4 ms; 6 kilohm,
Ni500, Ni1000, LG-Ni1000, Pt500, Pt1000: 13 ms
Interference voltage suppression for interference
frequency f1 in Hz
400 / 60 / 50 / 10 Hz
Basic execution time of the module (all channels
enabled)
Corresponds to the channel with the highest
basic conversion time
Smoothing of the measured values
Configurable
Yes
Level: None
Yes
Level: Weak
Yes
Level: Medium
Yes
Level: Strong
Yes
Encoders
Connection of the signal encoders
For voltage measurement
Yes
for resistance measurement with two
-wire connec-
tion
Yes
for resistance measurement with three
-wire con-
nection
Yes; all measuring ranges except PTC; internal
compensation of line resistance
For resistance measu
rement with four-wire con-
nection
Yes; all measuring ranges except PTC
