Siemens SIMATIC USB-Prommer

USB-Prommer
Commissioning Manual, 04/2020, A5E50041544-AA
13
Specifications
8
Plug-in power supply
Type number
FW8001/12
Supply voltage
100 – 240 V AC (+10%, -15%)
Frequency of the supply voltage
50/60 Hz (47 to 63 Hz)
Max. power consumption
18 W
Max. current output
12 V DC, 1.5 A
Primary adapter EURO
EURO connector, according to VDE 0620, part 101 or IEC 83/C5
Primary adapter USA
USA connector, according to ANSI C73.10 or IEC 8/AI-15
SIMATIC USB-Prommer
Order number
6ES7792-0AA00-0XA0
Dimensions
Approx. 172 x 121 x 40 mm
Weight
Approx. 400 g
Supply voltage 12 V DC, 1.25 A
Max. power consumption
15 W
Safety
Protection class Protection class I in accordance with VDE 0106 Part 1: (IEC
60536)
Safety specifications IEC 62368-1/EN 62368-1
UL 62368-1 Second Edition
CAN/CSA C22.2 No. 62368-1-14 Second Edition
Electromagnetic compatibility (EMC)
Emitted interference
Limit value class B according to EN55032
Immunity to line-borne interference on supply lines ±2 kV (according to IEC 61000–4–4; burst)
±1 kV (according to IEC 61000–4–5, surge symmetrical)
±2 kV (according to IEC 61000–4–5, surge asymmetrical)
Noise immunity on signal lines ±1 kV (according to IEC 61000–4–4; burst; length < 3 m)
±2 kV (according to IEC 61000–4–4; burst; length > 3 m)
Interference immunity against static electricity (ESD) ±4 kV, contact discharge (according to IEC 61000–4–2)
±8 kV, air discharge (according to IEC 61000–4–2)
Immunity to RF interference 10 V/m 80 MHz – 2 GHz, 80% AM 1 kHz
(according to IEC 61000–4–3)
3 V/m 2 – 6 GHz, 80% AM 1 kHz (according to IEC 61000–4–3)
RF current 10 V 10 kHz – 80 MHz, 80% AM 1 kHz (according to IEC 61000–
4–6)
Magnetic field
30 A/m 50 Hz (according to IEC 61000–4–8)
