Siemens SIMATIC Operating Manual

Panel Drivers and Tools software
1.3 Setup
PDT IFP Monitor Standard
8 Operating Manual, 10/2017, A5E41104536-AB
1.3
Setup
1.3.1
Initial commissioning of Monitor Standard
A PDT software is pre-installed on preconfigured SIMATIC IPC which automatically installs
the Configuration Center and the corresponding software component for the connected
device type.
Requirement
● The system requirements (Page 6) are met.
● Keyboard and mouse are connected to the PC.
● The SIMATIC IFP is connected to the PC with a matching video cable.
Note
Administrator rights required
Installation must be performed with a user account with administrator rights.
Procedure
1. Switch on the power supply of the PC.
2. Switch on the PC.
Installation of the PDT software starts automatically on preconfigured SIMATIC IPCs. If
not, see the section "Procedure for PCs that are not preconfigured".
3. The installation dialog opens: The installation steps on the left are are completed from top
to bottom.
First accept the license conditions and click "Next".
