Siemens SIMATIC Operating Instructions

Fail-Safe Electronic Modules
8.3 F -Switch PROFIsafe Digital Electronic Module
ET 200pro Distributed I/O System - Fail-Safe Modules
Operating Instructions, 05/2007, A5E00394073-02
115
Conditions for Achieving SIL/Category
The conditions for achieving the respective safety requirements are presented in the
following table.
Table 8-22 F-DI Modules: Conditions for Achieving SIL/Category
Use Case Sensors Evaluation of
the Sensors
Sensor Supply Achievable
SIL/Category
Internal, with short-
circuit test
Internal, without short-
circuit test
2.1 1-channel 1oo2
External
Internal, without short-
circuit test
2.2 2-channel
equivalent
1oo2
External
Internal, without short-
circuit test
2.3 2-channel
nonequivalent
1oo2
External
3 / 3
3.1 2-channel
equivalent
3.2 2-channel
nonequivalent
1oo2 Internal, with short-
circuit test
3 / 4
Note
You can operate the various inputs of an F-Switch PROFIsafe simultaneously in
SIL3/Category 3 and in SIL3/Category 4. You only have to connect the inputs and assign
parameters as shown in the following sections.
Sensor Requirements
Please note the information in section "Requirements for Sensors and Actuators" when using
sensors for safety-related applications.
See also
Use Case 1: Safety Mode of F-Switch PROFIsafe (Page 116)
