Fail-Safe Electronic Modules
8.3 F -Switch PROFIsafe Digital Electronic Module
ET 200pro Distributed I/O System - Fail-Safe Modules
Operating Instructions, 05/2007, A5E00394073-02
137
Technical Specifications
Insulation tested during type test with
• Shield and ET 200pro bus connection
370 V AC / 1 min or 520 V DC / 1 min
• ET 200pro bus connection and I/O
370 V AC / 1 min or 520 V DC / 1 min
• Shield and I/O (DIs, DOs)
370 V AC / 1 min or 520 V DC / 1 min
• Between DIs and DOs
370 V AC / 1 min or 520 V DC / 1 min
Current consumption
• From backplane bus
Max. 40 mA
• From the electronic supply (without load)
50 mA
• From load voltage L+ (without load)
Typ. 25 mA
Power loss of module 3 W
Status, Interrupts, Diagnostics
Status displays
• Inputs
Two-color red/green LED per channel
• Outputs
Two-color red/green LED per channel
• Sensor supply
LED VsF and display via channel LEDs of
channel group
Interrupts
• Diagnostic interrupt
Channel LED red
Diagnostic functions
• Group fault display
Red LED (SF)
• Diagnostic information can be read out
Possible
• I&M functionality *
See "ET 200pro Distributed I/O" Manual
Sensor Supply Outputs
Number of outputs 2
Output voltage
• Loaded
Min. L+ (-1.5 V)
Output current
• Rated value
200 mA
• Permissible range
0 mA to 200 mA
• Permissible aggregate current of outputs
400 mA
• Short-circuit protection
Yes, electronic
• Operating value
4 A to 9 A
Data for Selecting a Sensor **
Input voltage
• Rated value
24 V DC
• "1" signal
15 V to 30 V
• "0" signal
-30 V to 5 V
Input current
• "1" signal
Typ. 3.5 mA
Input delay For all inputs together
• For "0" after "1"
Typ. 3 ms 2.0 ms to 4.5 ms
• For "1" after "0"
Typ. 3 ms 2.0 ms to 4.5 ms
