Siemens SIMATIC Operating Instructions

Fail-Safe Connection Modules
7.1 CM IO 16xM12 Fail-Safe Connection Module for EM 8/16 F-DI DC24V PROFIsafe
ET 200pro Distributed I/O System - Fail-Safe Modules
50 Operating Instructions, 05/2007, A5E00394073-02
Terminal assignment
The terminal assignment depends on which electronic module is being used.
View Terminal Designation
X1 1. M12 circular socket
connector
X2 2. M12 circular socket
connector
X3 3. M12 circular socket
connector
X4 4. M12 circular socket
connector
X5 5. M12 circular socket
connector
X6 6. M12 circular socket
connector
X7 7. M12 circular socket
connector
X8 8. M12 circular socket
connector
X9 9. M12 circular socket
connector
X10 10. M12 circular socket
connector
X11 11. M12 circular socket
connector
X12 12. M12 circular socket
connector
X13 13. M12 circular socket
connector
X14 14. M12 circular socket
connector
X15 15. M12 circular socket
connector
X16 16. M12 circular socket
connector
Block Diagram
The following figure presents the block diagram of the CM IO 16 x M12 connection module.
; ;
. . .
Figure 7-1 Block Diagram of CM IO 16xM12 Connection Module
