Battery and Battery Pack
1.1 Battery on the CPU Module
62 Digital Fault Recorder, SIMEAS R/SIMEAS R-PMU, Maintenance Manual
E50417-H1074-C364-A2, Release 11.2009

Carefully pull the plug connectors of the two ribbon cables out of the CPU board and set the
front plate aside (see Figure 1-4).
Figure 1-4 Connection of ribbon cable

Remove the bus board from the modules and set it aside (see Figure 1-5).
Figure 1-5 Internal view of device without bus board
