Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-56
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-21 Induction motor 1PH7131-NF-0L
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
11 1500 70 24 10000 30 0.076 90
0
2
4
6
8
10
12
14
16
18
20
22
24
26
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
continuous
briefly
S6–25% (41.0 A)
S6–40% (34.0 A)
S6–60% (29.0 A)
S1 (24.0 A)
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (70 Nm, 24.0 A)
S6–60% (86 Nm, 29.0 A)
S6–40% (105 Nm, 34.0 A)
S6–25% (127 Nm, 41.0 A)
continuous
briefly
Fig. 2-18 1PH7131-NF-0L
