Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-66
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-31 Induction motor 1PH7137-ND-0L
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
17 1000 162 43 10000 30 0.109 130
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
S6–25% (68.0 A)
S6–40% (60.0 A)
S6–60% (50.0 A)
S1 (43.0 A)
continuous
briefly
0
40
80
120
160
200
240
280
320
0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (162 Nm, 43.0 A)
S6–60% (196 Nm, 50.0 A)
S6–40% (239 Nm, 60.0 A)
S6–25% (277 Nm, 68.0 A)
continuous
briefly
Fig. 2-28 1PH7137-ND-0L
