Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-67
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-32 Induction motor 1PH7137-NF
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
22 1500 140 57 8000 30 0.109 130
0
5
10
15
20
25
30
35
40
45
0 1000 2000 3000 4000 5000 6000 7000 8000
S6–25% (92.0 A)
S6–40% (79.0 A)
S6–60% (68.0 A)
S1 (57.0 A)
0
20
40
60
80
100
120
140
160
180
200
220
240
260
280
300
0 1000 2000 3000 4000 5000 6000 7000 8000
M [Nm] P [kW]
n [RPM]
n [RPM]
S1 (140 Nm, 57.0 A)
S6–60% (175 Nm, 68.0 A)
S6–40% (210 Nm, 79.0 A)
S6–25% (255 Nm, 92.0 A)
continuous
briefly
continuous
briefly
Fig. 2-29 1PH7137-NF
