Siemens Simodrive 1PH7 User Manual

Technical Data and Characteristics
2.2 Power-speed and torque-speed diagrams
1PH7/2-94
 Siemens AG, 2004. All rights reserved
Induction Motors, 1PH7 (APH7S) – 05.04 Edition
Table 2-59 Induction motor 1PH7186-NE
P
N
[kW]
n
N
[RPM]
M
N
[Nm]
I
N
[A]
n
max
[RPM]
T
th
[min]
J
[kgm
2
]
m
[kg]
60 1250 458 120 5000
7000
1)
40 0.67 460
0
10
20
30
40
50
60
70
80
0 1000 2000 3000 4000 5000 6000 7000
S6–40% (150.0 A)
S6–60% (135.0 A)
S1 (120.0 A)
P [kW]
n [RPM]
0
50
100
150
200
250
300
350
400
450
500
550
600
650
0 1000 2000 3000 4000 5000 6000 7000
n [RPM]
M [Nm]
continuous
briefly
2)
S1 (458 Nm, 120.0 A)
S6–60% (542 Nm, 135.0 A)
S6–40% (611 Nm, 150.0 A)
continuous
briefly
2)
Fig. 2-56 1PH7186-NE
____________
1) Optional
2) This only applies for bearing versions for coupling/belt out–drive.
For bearing versions designed for increased cantilever forces, this limit is at n=3000 RPM
For bearing versions designed for increased maximum speeds, this limit is at n=4500 RPM
