Siemens SIMODRIVE 611-D Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
1–224
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Dialog text
What must be done
or
What is wrong
Appears with the
following event
DECIMAL POINT NOT
ALLOWED
Taking over an input value
(e.g. with the input key)
––
DELETE DATA? “Delete” key has been
pressed
If pressed again the data
area specified will be
deleted
DIFFERENT PROGRAM
TYPES
When copying or renaming
part programs
Only identical program
types (L to L, % to %, etc.)
can be handled
DRIFT COMPENSATION
DATA ERROR
With semi-automatic drift
compensation
Repeat compensation
EDITING NOT ALLOWED When editing part
programs
Repeat input
ENTER PASSWORD When trying to enter
protected data
Enter password
FORMAT ERROR Taking over an input value
(e.g. with the input key)
The control can do nothing
with the value in this
position. See Operator’s
Guide.
FORMAT ERROR IN
DISPLAY DESCRIPTION
Cannot occur with the
user. (Only possible with
the machine manufacturer
during UMS testing.)
A format has been
specified in the display
description which does not
agree with that to be
displayed
GENERAL DATA ERROR Taking over an input value
(e.g. with the input key)
The value cannot be taken
over. Taking over the value
would cause an error:
change value
GENERAL INPUT ERROR Taking over an input value
(e.g. with the input key)
The value was wrong.
Change value
HELP NOT AVAILABLE Operating the “Help” key No help is available for the
display selected
INPUT DISABLED Taking over an input value
(e.g. with the input key)
Operate keyswitch
INPUT ERROR
(PROGRAM)
When editing part
programs
The character selected
cannot be entered in the
part program
INPUT LINE OVERFLOW Character input Max. 25 characters
INTERFACE ASSIGNED When starting data
input/output
Selected interface is
already operating
KEY NOT ALLOWED Taking over an input value
(e.g. with the input key)
Refers to input key and
delete keys
KEYSWITCH MISSING Selecting machine data
tree or with general reset
Operate keyswitch
“MB” NOT CONFIGURED When paging the menu
tree
The menu block/tree is
incorrectly configured
MD TRANSFER ERROR Data error when fetching
machine data
––
MDA CHANNEL
ASSIGNED
MDA has already been
started in another channel
Change channel or press
“Reset”
MDA MEMORY
OVERFLOW
In “MDA” mode Max. 500 characters may
be entered
NO CORRECTION
BLOCK
With “Correction block”
function
Correction block cannot be
selected
1 Alarms
1.6.2 Listing of dialog texts
