Siemens SIMODRIVE 611-D Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
2–9
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Contents/DesignationAddressError No.
3C F0000
F0001
F0002
F0003
3C: Error number MD double addressing inputs
Group number (BCD format)
––
––
3D F0000
F0001
F0002
F0003
3D: Error number MD double addressing outputs
Group number (BCD format)
––
––
3E F0000
F0001
F0002
F0003
3E: Error number output group per MD for several PLCs
Group number (BCD format)
––
––
45 F0000
F0001
F0002
F0003
45: Error number illegal version of interface DMP firmware
Number of interface module
Illegal (fitted) firmware interface-DMP
Required firmware interface-DMP ++)
47 F0000
F0001
F0002
F0003
47: Error number double addressing inputs
Byte number (BCD format)
––
––
48 F0000
F0001
F0002
F0003
48: Error number double addressing outputs
Byte number (BCD format)
––
––
49 F0000
F0001
F0002
F0003
49: Error number modification of I/O modules
3C: Changed address location of I/O byte
00: I/O failure
0I or 0Q identifier input/output
Byte number (BCD format)
55, 56, 57,
58, 59, 5A,
5B, 5C, 5D,
5E, 60, 61,
70, 71
F0000
F0001
F0002
F0003
Respective error number
Segment address of fault block
Offset address (byte-oriented) of fault block (segment and offset point to the
synchronization pattern) ++)
––
2 Diagnostics on the PLC
2.2 Additional error information (ACCU 3 low byte, DB 1 DW 161–163)
