SINUMERIK 840C / SIMODRIVE 611–D (DA)
Error No. Address Contents/Designation
6F F0000
F0001
F0002
F0003
F0004
6F: Error number I/O fault on start-up
Type of link:
03: 16-bit
04: DMP
Number of the interface module
EU number or DMP module number
Line (MPC) number for DMP ++)
92 F0000
F0001
F0002
F0003
92: Error number timeout for buffered access to link (local bus
Bus address (segment), where timeout occurs
Bus address (offset), where timeout occurs
Type identifier of the timeout **) ++)
93 F0000
F0001
F0002
F0003
93: Error number timeout with system progr. processing
CS when timeout occurs
IP when timeout occurs
Type identifier of the timeout **) ++)
94 F0000
F0001
F0002
F0003
94: Error number timeout with LIR/TIR
OPCODE command
Offset address
Segment number ++)
95 F0000
F0001
F0002
F0003
95: Error number timeout with TNB/TNW
OPCODE command
Offset address
Segment number ++)
96 F0000
F0001
F0002
F0003
96: Error number timeout with LPB/LPW/TPB/TPW
OPCODE command
Specification of input or output
Byte number (BCD format) ++)
99 F0000
F0001
F0002
F0003
99: Error number Error number timeout not interpretable when interpreter
active
CX when timeout occurs
IP when timeout occurs
Type identifier of the timeout **) ++)
9A F0000
F0001
F0002
F0003
9A: Error number timeout when processing a function macro
OPCODE of the command that called the function macro
Command parameter (with FX only, otherwise 0000)
Type identifier of the timeout **)
2 Diagnostics on the PLC
2.2 Additional error information (ACCU 3 low byte, DB 1 DW 161–163)
**) Type identifier of timeout:
0001 = Internal timeout
0002 = Link bus timeout
0003 = Local bus timeout
