Siemens SIMODRIVE 611-D Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
5–3
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Service Remedy
number Significance
General Axis Spindle
329
(SW 3 and
higher)
Errors in setpoint/actual value assignment.
Double assignment of measuring circuit input/
output.
MD 200*
384*
1388*
1824*
Bit 2
MD 400*
460*
522*
Bit 2
and/or
With SW 5.4 and higher: The measuring circuit
connection (MD 4100*) allocated to SI has al-
ready been assigned to another axis/spindle.
Note: If SI is operated with an encoder, the se-
cond measuring circuit can no longer be alloca-
ted freely.
MD 4100* MD 4100*
330
(SW 4 and
higher)
Invalid values have been entered in the ma-
chine data for Master/Slave mode
(MD 1336*/2700* oder 1340*/2701*):
S The axis/spindle entered there does not
exist.
S A rotary axis has been assigned to a linear
axis or vice versa. Only the following are
allowed: 2 rotary axes or 2 spindles or 2
linear axes or 1 rotary axis to a spindle.
S In a specific/C-axis combination, different
axes/spindles have been assigned.
S An axis has been entered in the
MD 1340*/2701*.
S The entered axis/spindle has a different po-
sition controller cycle.
S Parameterized axis/spindle is contained in a
different mode group
MD 1336*
1340*
MD 2700*
2701*
331
(SW 5.4
and higher)
Errors have occurred during conversion of
SI-MD.
MD 4184*
to
4196*
4200*
to
4244*
4248*
to
4260*
4180*
MD 4184*
to
4196*
4200*
to
4244*
4248*
to
4260*
4180*
Evaluate detailed informa-
tion in the SI SERVICE
SCREEN (service data
1000).
END OF SECTION
5 Parameterization Errors Spindle/Axis
