SINUMERIK 840C / SIMODRIVE 611–D (DA)
No. Cause, RemedyExplanationName
35 Delay time pulse deletion MD 4268* and MD 1356 are not identical Enter the same MD values
36 Time for pulse deletion check MD 4272* and MD 1357 are not identical Enter the same MD values
37 Transition time STOP C to
SBH
MD 4276* and MD 1352 are not identical Enter the same MD values
38 Transition time STOP D to
SBH
MD 4280* and MD 1353 are not identical Enter the same MD values
39 Transition time STOP E to
SBH
MD 4284* and MD 1354 are not identical Enter the same MD values
40 Stop reaction after SG MD 4508*.4,4508*.5 and MD 1361 are not identical Enter the same MD values
41 Stop reaction after SE MD 4508*.2,4508*.3 and MD 1362 are not identical Enter the same MD values
42 Shut–down speed pulse dele-
tion
MD 4288* and MD 1360 are not identical Enter the same MD values
43 Memory test stop reaction – –
44 Position actual value+limit va-
lue SG1
Position actual value (error code 3) different or
MD 4184* and MD 1331[0] not equal (error code 6)
–
45 Position actual value–limit va-
lue SG1
Position actual value (error code 3) different or
MD 4184* and MD 1331[0] not equal (error code 6)
–
46 Position actual value+limit va-
lue SG2
Position actual value (error code 3) different or
MD 4188* and MD 1331[1] not equal (error code 7)
–
47 Position actual value–limit va-
lue SG2
Position actual value (error code 3) different or
MD 4188* and MD 1331[1] not equal (error code 7)
–
48 Position actual value+limit va-
lue SG3
Position actual value (error code 3) different or
MD 4192* and MD 1331[2] not equal (error code 8)
–
49 Position actual value–limit va-
lue SG3
Position actual value (error code 3) different or
MD 4192* and MD 1331[2] not equal (error code 8)
–
50 Position actual value+limit va-
lue SG4
Position actual value (error code 3) different or
MD 4196* and MD 1331[3] not equal (error code 9)
–
51 Position actual value–limit va-
lue SG4
Position actual value (error code 3) different or
MD 4196* and MD 1331[3] not equal (error code 9)
–
52 Standstill position + tolerance Position actual value (error code 3) different or
MD 4180* and MD 1330 not equal (error code 10)
–
53 Standstill position – tolerance Position actual value (error code 3) different or
MD 4180* and MD 1330 not equal (error code 10)
–
54 Position actual value+n
x
+tole-
rance
Position actual value (error code 3) different or
MD 4292* and MD 1346 not equal (error code 75)
or MD 4256* and MD 1342 not equal (error
code 31)
–
55 Position actual value+n
x
Position actual value (error code 3) different or
MD 4292* and MD 1346 not equal (error code 75)
–
56 Position actual value–n
x
Position actual value (error code 3) different or
MD 4292* and MD 1346 not equal (error code 75)
–
57 Position actual value–n
x
–tole-
rance
Position actual value (error code 3) different or
MD 4292* and MD 1346 not equal (error code 75)
or MD 4256* and MD 1342 not equal (error
code 31)
–
58 Stop request MD 1301 bit 6 is not 0 –
59 SG correction factor 1 MD 1301 bit 5 is not 0 –
60 SG correction factor 2 MD 1301 bit 5 is not 0 –
61 SG correction factor 3 MD 1301 bit 5 is not 0 –
62 SG correction factor 4 MD 1301 bit 5 is not 0 –
63 SG correction factor 5 MD 1301 bit 5 is not 0 –
64 SG correction factor 6 MD 1301 bit 5 is not 0 –
65 SG correction factor 7 MD 1301 bit 5 is not 0 –
66 SG correction factor 8 MD 1301 bit 5 is not 0 –
67 SG correction factor 9 MD 1301 bit 5 is not 0 –
68 SG correction factor 10 MD 1301 bit 5 is not 0 –
69 SG correction factor 11 MD 1301 bit 5 is not 0 –
70 SG correction factor 12 MD 1301 bit 5 is not 0 –
71 SG correction factor 13 MD 1301 bit 5 is not 0 –
72 SG correction factor 14 MD 1301 bit 5 is not 0 –
1 Alarms
1.5.1 Alarm description
07/97
