1FT6 Synchronous Motors
Configuration Manual, (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
3-133
Technical Data and Characteristics
Axial forces
3.3 Axial forces
Axial force stressing
When using, for example, helical toothed wheels as drive element, in addition to the radial
force, there is also an axial force on the motor bearings. For axial forces, the spring-loading of
the bearings can be overcome so that the rotor moves corresponding to the axial bearing play
present (up to 0.2 mm).
The permissible axial force can be approximately calculated using the following formula:
F
A
= 0.35 • F
Q
Warning
Motors with integrated holding brake cannot be subject to axial forces!
