1FT6 Synchronous Motors
Configuration Manual (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
3-1
Technical Data and Characteristics 3
3.1 Speed-torque diagrams
3.1.1 Introduction
Note
Refer to the Configuration Manual "General Section for Synchronous Motors" for a description
of how the voltage limiting characteristics are shifted.
The specified thermal S3 limit characteristics are referred to ∆T = 100 K for
- 1 min cycle duration for SH 28
- 10 min cycle duration for SH 36, 48, 63, 80, 100, 132, 160
