Electrical Connections
Connection through a terminal box
1FT6 Synchronous Motors
2-4 Configuration Manual, (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
Routing cables in a wet/moist environment
Fig. 2-3 Routing cables in a wet/moist environment
Notice
For motors in wet/moist environments, cables should be routed as shown in the following
diagram.
SIEMENS
SIEMENS
SIEMENS
SIEMENS
SIEMENS
SIEMENS
SHUPLWWHG
QRWSHUPLWWHG
