Siemens Simodrive 611 Configuration Manual

Motor Components (Options)
Output coupling
1FT6 Synchronous Motors
4-2 Configuration Manual, (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
Table 4-1 Assignment of the output couplings to the motors
Shaft height of
the
1FT6 motor
d
w
[mm]
1)
Rotex GS
Size
98 Sh A GS
TR [Nm]
4)
TKN [Nm]
2)
TKmax [Nm]
3)
1FT602 9 9 5 10 2,6
1FT603 14 14 12,5 25 8,1
1FT6041 19 19 17 34 32
1FT6044 19 24 60 120 39
1FT606x–6A 24 24 60 120 43
1FT6062–6W 24 24 60 120 43
1FT6064–6W 24 28 60 120 91
1FT608x–8A 32 28 160 320 102
1FT608x–8S 32 28 160 320 102
1FT6084–8W 32 28 160 320 102
1FT6086–8W 32 38 325 650 113
1FT6102..5 38 38 325 650 122
1FT6108 38 42 450 900 ––
1FT613x–6A 48 42 450 900 ––
1FT613x–6S 48 42 450 900 ––
1FT6132..4–6W 48 48 525 1050 ––
1FT6136..8–6W 48 55 685 1370 ––
1FT6163 55 65
940
5)
1880
5)
––
1FT6168 55 75
1920
5)
3840
5)
––
1) d
w
= diameter, motor shaft end
2) T
KN
= rated coupling torque
3) T
Kmax
= maximum coupling torque
4) T
R
= friction-locked torque (torque that can be transmitted using a clamping hub at d
w
)
5) Values for 95 Sh A GS
Warning
The accelerating torque may not exceed the friction-locked torque of the coupling!
Notice
We cannot accept any liability for the quality and properties/features of third-party products.
