1FT6 Synchronous Motors
Configuration Manual, (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
5-7
Planetary Gearbox
Series SP+
5.2.1.4 Selection and ordering data, single-stage planetary gearbox, series SP+
Motor
Natural
cooling
Planetary gearbox
1-stage
Available
gearbox ratio i =
Max. perm.
motorspeed
S3-60%
Max. perm.
output
torque
S3-60%
Max. perm.
radial output-
shaft
load
3)
Max. perm.
axial
outputshaft
load
3)
Type Type Tor-
sional
back-
lash
Gear unit
weight
approx.
4 5 7 10 n
G1
(n
1
)
M
G2
(T
2B
)
F
r
(F
2Rmax
)
F
a
(F
2Amax
)
arcmin kg rpm Nm N 10
-4
kgm
2
1FT6021
1FT6024
SP 060S-MF1 = 4 1.9 –
✔
–
✔
–
✔
✔
✔
6000 40
(32 for i = 10)
2700 2400
1FT6031
1FT6034
✔
✔
✔
✔
✔
✔
✔
–
1FT6034
SP 075S-MF1 = 4 3.9 – ––
✔
6000 110
(90 for i = 10)
4000
3350
1FT6041
1FT6044
✔
✔
✔
✔
✔
✔
✔
✔
1FT6061
1FT6062
1FT6064
SP 100S-MF1 = 3 7.7
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
4500 300
(225 for i = 10)
6300 5650
1FT6081
1FT6082
1FT6084
1FT6086
SP 140S-MF1 = 3 17.2
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
–
4000 600
(480 for i = 10)
9450 9870
1FT6086
SP 180S-MF1 = 334 – ––
✔
3500 1100
(880 for i = 10)
14700 14150
1FT6102
1FT6105
1FT6108
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
–
–
1FT6105
1FT6 108
SP 210-MF1
2)
= 453 –
–
–
–
–
–
✔
✔
2500 1900
(1520 for i = 10)
18000 22500
1FT6132
1FT6134
1FT6136
✔
✔
✔
✔
✔
✔
✔
✔
✔
✔
–
–
1FT6134
1FT6136
SP 240-MF1
2)
= 480 –
–
–
–
–
–
✔
✔
2200 2720 27000 27800
Order codes
• Gearbox shaft with key J02 J03 J05 J09
• Gearbox shaft without key J22 J23 J25 J29
Ordering data 1FT6 ...-. A . 7 1-.. 7 1-Z Order No. of the motor with identifier "-Z" and
order code for mounting the planetary gearbox assigned to the motor
Prerequisite when mounting planetary gearboxes:
Plain motor shaft end/radial eccentricity tolerance N and vibration severity grade N/IP65
degree of protection
1)
J 7 7
G
H
1) IP64 degree of protection with 1FT602.: 1FT602.-6AK71-.. 7 0 -Z J..
2) For these versions, the quantity of oil in the gearbox depends on the mounting position. In the case of a vertical mounting position, the 12th position in the
Order No. should be "9" and a further order code also has to be specified: 1FT6...-.A.79-.. 7 1-Z J.. + M1 7
3) Referred to the center of the drive shaft.
G
H
G
H
H mounting position IM V1
G mounting position IM V3
