1FT6 Synchronous Motors
Configuration Manual, (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
6-9
Dimension Drawings
Naturally cooled 1FT6 motors
Fig. 6-8 1FT613 naturally cooled with connector, Size 1.5/3
e changed 27.11.03 Gtz/Dö
f Revision 12.08.04 Fuß/Re
c Connector assignment correct.
Fuß/Re
08.12.00
plug size 1.5
plug size 3
d CM 500730 20.08.03 MG/MJ
plug
rated speed
size 1.5 size 3
shaft
height
12-pole plug for resolver
17-pole plug for optical encoder
6-pole plug size 1.5 or 3
for power and brake
centre hole
2
350
32
260
14
51.5
50
23
133
Ø
18
45
°
±
0.5
5
82
±0.5
82
±0.5
Ø 48
k6
Ø 250
h6
18 62
k= without brake / k1 = with brake
245
R
24
6 70
132
35
Ø
300
±0.5
76
33
67
deviation acc. to DIN 6885 sheet 1
DIN 332 DR M16
1FT6132
1FT6134
1FT6136
132
132
132 117
100
85
125
110
95
523
473
423
573
523
473
Z
version with featherkey
Z
rpm
<=1500
<=2000
<=2000 >2000
>1500
>2000
1
A
B
C
D
E
F
2 3 4 5 6 7 8
1 2 3 4
A
B
C
D
E
sheet
No.
total
sheets
scale: without
index information date name/respons.
date:
name:
respons.:
dept.:A&D MC EWN K-T
16.06.93
Baumeister
replacement for:
Siemens AG
Dimension sheet
natural air cooling with plug
510.37511.01
1
1
1FT613.-6A
Sigraph
DESIGN
f
Doelz
plug direction:
transverse - right transverse - left axial - DE
flange and shaft
tolerances acc. to
DIN 42955
not toleranced
dimensions ±1mm
weight
without brake with brake
resolver/encoder
mm kg mm
type
k k1
Fit tol. Tol.
48 k6
+0.018
+0.002
250 h6
0
-0.029
