Siemens Simodrive 611 Configuration Manual

Technical Data and Characteristics
Speed-torque diagrams
1FT6 Synchronous Motors
3-22 Configuration Manual, (PFT6), 10.2005 Edition, 6SN1197-0AD02-0BP1
Table 3-11 1FT6064 natural cooling
1FT6064
Technical data Code Units -6AC7 -6AF7
Engineering data
Rated speed n
N
rpm 2000 3000
Number of poles 2p 6 6
Rated torque (100 K)
M
N(100 K)
Nm 8.0 7.0
Rated current (100K)
I
N
A3.84.9
Stall torque (60K)
M
0(60 K)
Nm 7.9 7.9
Stall torque (100K)
M
0(100 K)
Nm 9.5 9.5
Stall current (60K)
I
0(60 K)
A3.44.9
Stall current (100K)
I
0(100 K)
A4.26.1
Moment of inertia (with brake)
J
mot
10
–4
kgm
2
16.3 16.3
Moment of inertia (without brake)
J
mot
10
–4
kgm
2
13 13
Optimum operating point
Optimum speed
n
opt
rpm 2000 3000
Optimum power
P
opt
kW 1.68 2.20
Limiting data
Max. permissible speed (mech.)
n
max
rpm 9100 9100
Maximum torque
M
max
Nm 38 38
Maximum current
I
max
A2333
Physical constants
Torque constant
k
T
Nm/A 2.26 1.57
Voltage constant
k
E
V/1000 rpm 144 100
Winding resistance at 20 °C
R
ph
Ohm 2.93 1.40
Rotating field inductance
L
D
mH 28 13.5
Electrical time constant
T
el
ms 9.6 9.6
Shaft torsional stiffness
c
t
Nm/rad 27000 27000
Mechanical time constant
T
mech
ms 2.2 2.2
Thermal time constant
T
th
min 35 35
Weight with brake m kg 13 13
Weight without brake m kg 12.5 12.5
