COMPONENT LEVEL PART NUMBERS FOR 611-A SINGLE AND DOUBLE AXIS FEED MODULES
9/30/98
TYPE OF ORIGINAL, COMPLETE COMPONENT LEVEL PART NUMBERS MODULE
MODULE RATING MODULE ASSEMBLY POWER SECTION CONTROLLER PCB SETTING BOARD WIDTH
SINGLE AXIS COMFORT 4/8 A 6SN1130-1AA11-0GA0 6SN1123-1AA00-0HA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
*
COMFORT WITH SPINDLE OPTION
4/8 A 6SN1130-1AA12-0GA0 6SN1123-1AA00-0HA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
**
SINGLE AXIS STANDARD 4/8 A 6SN1130-1AD11-0GA0 6SN1123-1AA00-0HA1 6SN1118-0AD11-0AA1 N / A 50 mm
**
DOUBLE AXIS MODULE 4/8 A 6SN1130-1AE11-0GB0 6SN1123-1AA00-0HA1 6SN1118-0AE11-0AA1 N / A 50 mm SINGLE AXIS COMFORT 7.5/15 A 6SN1130-1AA11-0AA0 6SN1123-1AA00-0AA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
*
COMFORT WITH SPINDLE OPTION
7.5/15 A 6SN1130-1AA12-0AA0 6SN1123-1AA00-0AA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
**
SINGLE AXIS STANDARD 7.5/15 A 6SN1130-1AD11-0AA0 6SN1123-1AA00-0AA1 6SN1118-0AD11-0AA1 N / A 50 mm
**
DOUBLE AXIS MODULE 7.5/15 A 6SN1130-1AE11-0AB0 6SN1123-1AA00-0AA1 6SN1118-0AE11-0AA1 N / A 50 mm SINGLE AXIS COMFORT 12.5/25 A 6SN1130-1AA11-0BA0 6SN1123-1AA00-0BA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
*
COMFORT WITH SPINDLE OPTION
12.5/25 A 6SN1130-1AA12-0BA0 6SN1123-1AA00-0BA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
**
SINGLE AXIS STANDARD 12.5/25 A 6SN1130-1AD11-0BA0 6SN1123-1AA00-0BA1 6SN1118-0AD11-0AA1 N / A 50 mm
**
DOUBLE AXIS MODULE 12.5/25 A 6SN1130-1AE11-0BB0 6SN1123-1AA00-0BA1 6SN1118-0AE11-0AA1 N / A 50 mm SINGLE AXIS COMFORT 25/50 A 6SN1130-1AA11-0CA0 6SN1123-1AA00-0CA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
*
COMFORT WITH SPINDLE OPTION
25/50 A 6SN1130-1AA12-0CA0 6SN1123-1AA00-0CA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 50 mm
**
SINGLE AXIS STANDARD 25/50 A 6SN1130-1AD11-0CA0 6SN1123-1AA00-0CA1 6SN1118-0AD11-0AA1 N / A 50 mm
**
DOUBLE AXIS MODULE 25/50 A 6SN1130-1AE11-0CB0 6SN1123-1AA00-0CA1 6SN1118-0AE11-0AA1 N / A 50 mm SINGLE AXIS COMFORT 40/80 A 6SN1130-1AA11-0DA0 6SN1123-1AA00-0DA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 100 mm
*
COMFORT WITH SPINDLE OPTION
40/80 A 6SN1130-1AA12-0DA0 6SN1123-1AA00-0DA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 100 mm
**
SINGLE AXIS STANDARD 40/80 A 6SN1130-1AD11-0DA0 6SN1123-1AA00-0DA1 6SN1118-0AD11-0AA1 N / A 100 mm SINGLE AXIS COMFORT 80/160 A 6SN1130-1AA11-0EA0 6SN1123-1AA00-0EA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 150 mm
*
COMFORT WITH SPINDLE OPTION
80/160 A 6SN1130-1AA12-0EA0 6SN1123-1AA00-0EA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 150 mm
**
SINGLE AXIS STANDARD 80/160 A 6SN1130-1AD11-0EA0 6SN1123-1AA00-0EA1 6SN1118-0AD11-0AA1 N / A 150 mm SINGLE AXIS COMFORT 100/200 A 6SN1130-1AA11-0FA0 6SN1123-1AA01-0FA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 300 mm
*
COMFORT WITH SPINDLE OPTION
100/200 A 6SN1130-1AA12-0FA0 6SN1123-1AA01-0FA1 6SN1118-0AA11-0AA1 6SN1114-0AA01-0AA0 300 mm
**
SINGLE AXIS STANDARD 100/200 A 6SN1130-1AD11-0FA0 6SN1123-1AA01-0FA1 6SN1118-0AD11-0AA1 N / A 300 mm
All component level part numbers in the chart reflect the 'V3' version replacement components.
** NOTE: NO SETTING BOARD IS USED FOR THE STANDARD OR TWO AXIS VERSION FEED MODULES.
* NOTE: THE MAIN SPINDLE OPTION CAN ONLY BE SUPPLIED WITH THE SINGLE AXIS COMFORT VERSION 611-A. MAIN SPINDLE OPTION PCB ( 6SN1114-0AA02-0AA0 )
MUST ALSO BE ORDERED IN ADDITION TO THE CONTROLLER AND SETTING BOARDS.
611acomp.xls VS 611A
1-183
