AL S
08.95
AL S/1-9
Siemens AG 1997 All Rights reserved 6SN1197–0AA20
SIMODRIVE 611 (PJ)
1.2 Rating plate data
Example from the 1FT6 series:
No. E 1Q62 7603 01 001
M
0
= 3.3/4.0 Nm l
0(RMS)
= 2.25/2.75 A 60/100 K
M
n
= 3.50 Nm S1 3000 RPM Ui(RMS) = 282 V Y
(M
= 3.75 Nm S1 1500 RPM Ui(RMS) = 141 V Y)
IEC 63 IMB5 IP 64 I.CL.F VDE 0530 PTC Therm.
Encoder
”Encoder type”
nmax. 4200 RPM
Brake EBD ... 24 V/20 W
SIEMENS
Brushless servomotor
1FT6061–1AF71–4AG0
MADE IN GERMANY
Holding brake EBD type
Operating voltage, power drain
Encoder (tacho, encoder, resolver)
Frame size (shaft height), type of construction,
Degree of protection, insulating material class,
thermal protection
Rated torque for S1 duty at
rated speed, induced phase–to–phase, RMS motor
voltage
2nd line: Additional operating point
(for 230V drive converter input voltage)
Stall torque/stall current
at 60/100 K winding temperature rise
Serial number
16–digit motor Order No.
J
General information on AC servomotors
1.2 Ratin
plate data01.98
