AL S
08.95
AL S/2-9
Siemens AG 1997 All Rights reserved 6SN1197–0AA20
SIMODRIVE 611 (PJ)
The permissible axial forces are shown in the diagrams for the appropriate mo-
tors.
!
Caution
For motors with integrated holding brake, no axial forces are permitted!
When using, e.g. gear wheels with helical teeth as the drive element, in addition
to the radial force, the bearing is also subject to an axial force. For axial forces
acting towards the motor, the bearing alignment force can be overcome, so that
the rotor can move corresponding to the actual bearing axial play (to 0.2 mm).
The permissible axial force can be approximated using the following formula:
F
A
= 0.35 F
Q
More accurate data can be taken from the diagrams, taking into account the
mounting position.
Table 2-8 Paint finish for 1FT5, 1FT6 and 1FK6
1FT5, 1FT6
1FK6
Anthracite (SN30901–614)
Two–component epoxy resin paint;
No special paint finish is required for the
tropics.
Primer finish; without final paint finish
Axial force
stressing
Paint finish
General information on AC servomotors
2.1 Definitions
