1FT5
08.95
1FT5/1-5
Siemens AG 1997 All Rights reserved 6SN1197–0AA20
SIMODRIVE 611 (PJ)
Rated
speed
[RPM]
M
0
[Nm]
M
rated
[Nm]
Motor type
1FT5–
Motor
current
I
0
[A]
Rated
drive
converter
current[A]
P
rated
[kW]
Connec-
tor size
Cross–
section
1)
[mm
2
]
Cable type
6FXV002–
3)
Motors, short type of construction
2000 3.5
5.5
9.
13
19
25
3.1
5
8
12
17
22.5
070–0AC71
071–0AC71
073–0AC71
100–0AC71
101–0AC71
103–0AC71
3.1
5.2
8.2
12.0
18.0
23.0
4
4
7.5
12.5
12.5
25
0.65
1.0
1.7
2.5
3.6
4.7
1
1
1
2
2
2
4x1.5
4x1.5
4x1.5
4x2.5
4x2.5
4x2.5
5VA01–1VV0
5VA01–1VV0
5VA01–1VV0
5VA02–1VV0
5VA02–1VV0
5VA02–1VV0
3000 3.5
5.5
9
13
19
25
3.0
4.8
7.2
11
15
20
070–0AF71
071–0AF71
073–0AF71
100–0AF71
101–0AF71
103–0AF71
3.1
5.2
8.2
12.0
18.0
23.0
4
7.5
12.5
12.5
25
25
0.94
1.5
2.3
3.5
4.7
6.3
1
1
1
2
2
2
4x1.5
4x1.5
4x1.5
4x2.5
4x2.5
4x4
5VA01–1VV0
5VA01–1VV0
5VA01–1VV0
5VA02–1VV0
5VA02–1VV0
5VA12–1VV0
without brake cable: without overall screen A
with overall screen C
with brake cable: without overall screen B
with overall screen D
Lengths
2)
5 m AF
(examples) 10 m BA
15 m BF
18 m BJ
25 m CF
Cables are not included with the motors,
they must be separately ordered.
Actual value cable, refer to Chapter, Encoders (GE).
P [kW] +
M
0 n
9550
M [Nm]
n [RPM]
Power calculation
1) Designed for I
0rms
= I
0[100
k]
2/3 ; ambient temperature 40 °C; PVC insulated cable; brake connection 2 x 1 mm
2
.
2) Cables can be supplied in incremental lengths of 1 meter; length code, refer to Chapter AL S/4.3.
3) 2=Performance cable; 4=Standard cable; Technical data, refer to Catalog NC Z
1FT5 AC servomotors
01.98 1.1 Characteristics and technical data
