SIMODRIVE 611 (PJ)
Note
The 28 kW UE module does not include a pulsed resistor.
Ext. pulsed resistor
Screen connection
Figure 3-9Connecting an external pulsed resistor with screen connection
Table 3-7 Permissible methods of connecting an external pulsed resistor to UE 28
kW
Pulsed resistor (PR)
Terminal block TR1 Terminal block TR2
0.3/25 kW
1R
2R
3R
*
PR
0.3
kW
1R
2R
3R
2 x 0.3/25 kW=0.6/50 kW
1R
2R
3R
*
PR
0.3
kW
1R
2R
3R
*
PR
1.5/25 kW
1R
2R
3R
PR
1.5
kW/25
1R
2R
3R
2 x 1.5/25 kW=3/50 kW
1R
2R
3R
PR
1.5 kW
1R
2R
3R
PR
1.5 kW
* Jumper to code the thermal limiting characteristic
28 kW UE module
Possibilities of
connecting exter-
nal pulsed resi-
stors to the 28 kW
module
3.2.1 Technical data, supply infeed modules
