3
02.98
1-53
 Siemens AG 1998 All Rights reserved 6SN1197–0AA00 02.98 Edition
SIMODRIVE 611 (PJ)
Assignment of the line filters to the UE modules
Table 3-19
UE module
5/10 kW
UE module
10/25 kW
UE module
28/50 kW
Filter components Line filter, 5 kW Line filter, 10 kW Line filter, 28 kW
Order No. filter module 6SN1111–0AA01–1BA0 6SN1111–0AA01–1AA0 6SN1111–0AA01–1CA0
Mounting position Any
Module width Refer to Dimension Drawings, Section 12
Filter Filter 3.8 kg 5.7 kg 12.5 kg
I
rated
filter 16 A 25 A 65 A
P
v
filter 20 W 20 W W25
Max. connection cross–sec-
tion
4 mm
2
PE, M6 studs
10 mm
2
PE, M6 studs
50 mm
2
PE, M10 studs
Terminals,
Line input
LINE
L1, L2, L3, PE
LINE
L1, L2, L3, PE
LINE
L1, L2, L3, PE
Terminals,
output
LOAD
L1, L2, L3, PE
LOAD
L1, L2, L3, PE
LOAD
L1, L2, L3, PE
I
rated
, fuse
1)
16 A 25 A 80 A
Cooling Non–ventilated Non–ventilated Non–ventilated
Radio interference suppres-
sion
EN 55011
Cable–borne,
limit value Class A
Cable–borne
limit value Class A
Cable–borne
limit value Class A
1)The fuse used must have this rated current. Refer to Table 3-10 for recommended fuses.
3.5.4 Assignment of the line filters to the UE modules
