SIMODRIVE 611 (PJ)
Assignment of the line filters to the I/R modules
Table 3-17 Assignment of the line filters to the I/R modules
I/R module
16/21 kW
I/R module
36/47 kW
I/R module
55/71 kW
I/R module
80/104 kW
I/R module
120/156
kW
Filter
components
Line filter 16 kW Line filter 36 kW Line filter 55 kW Line filter 80 kW Line filter 120 kW
Order No.
Line filter
6SN1111–
0AA01–2BA
6SN1111–
0AA01–2CA
6SN1111–
0AA01–2DA
6SN1111–
0AA01–2EA
6SN1111–
0AA01–2FA
Mounting posi-
tion
Wall– or floor mounting, refer to dimension drawings, Section 12.
Module width Refer to the dimension drawings, Section 12.
Filter Filter 9 kg 16 kg 19 kg being prepared being prepared
I
rated
filter 30 A 67 A 103 A 150 A 225 A
P
v
filter W70 W90 W110 being prepared being prepared
Max. connection
cross–section
16/10mm
2
1)
PE, (M5)
50mm
2
PE, (M8)
50mm
2
PE, (M8)
being prepared being prepared
Terminals,
Line supply input
LINE
L1, L2, L3, PE
LINE
L1, L2, L3, PE
LINE
L1, L2, L3, PE
LINE
L1, L2, L3, PE
LINE
L1, L2, L3, PE
Terminals,
output
LOAD
L1, L2, L3
LOAD
L1, L2, L3
LOAD
L1, L2, L3
LOAD
L1, L2, L3
LOAD
L1, L2, L3
I
rated
, fuse
2)
35 A 80 A 125 A 160 A 250 A
Cooling Non–ventilated Non–ventilated Non–ventilated Non–ventilated Non–ventilated
Radio interfe-
rence suppres-
sion
EN 55011
Cable–borne, limit
value Class A
Cable–borne, limit
value Class A
Cable–borne, limit
value Class A
Cable–borne, limit
value Class A
Cable–borne, limit
value Class A
Table 3-18 Filter packages
Filter packages
Package 16kW
6SN1111–
0AA01–2BB0
Package 36kW
6SN1111–
0AA01–2CB0
Package 55kW
6SN1111–
0AA01–2DB0
Package 80kW
6SN1111–
0AA01–2EB0
Package 120kW
6SN1111–
0AA01–2FB0
Contents:
6SN1111–0AA00
–
16kW HF commu-
tating reactor
–0BA
36kW HF commu-
tating reactor
–0CA
55kW HF commu-
tating reactor
–0DA
80kW HF commu-
tating reactor
–1EA
120kW HF com-
mutating reactor
–1FA
6SN1111–0AA01
–
16 kW line filter
–2BA
36 kW line filter
–2CA
55 kW line filter
–2DA
80 kW line filter
–2EA
120 kW line filter
–2FA
The filter modules can be mounted horizontally and vertically (line at the bottom,
load at the top).
1)The 1st number is for cable lugs, the 2nd number is for finely–stranded conductors without connector sleeves
2)The fuse used must have this rated current. Refer to Table 3-10 for recommended fuses.
Mounting position
of the filter
modules
3.5.2 Assignment of the line filters to the I/R modules
