3
02.98
1-57
Siemens AG 1998 All Rights reserved 6SN1197–0AA00 02.98 Edition
SIMODRIVE 611 (PJ)
G
G
Function
cables
Connect the PE – bar through the largest possible surface area to the cabinet mounting panel
Cabinet mounting panel
1)
U/E module
5kW
10kW
2)
MSD module
2)
FD module
P600
M600
2)
M
M
1)
1)
1)
1)
Supply
1)Shield connection, connected through the largest possible surface area with the cabinet mounting panel.
2)Shield connection at the module–specific connecting panel
Encoder cables
1)
1)
Fuses
Incoming terminals
Main switch
LINE
LOAD
PE
L3
L1
L2
L3
L1
L2
PE PE
PE
L2
L3L1
PE
V1U1 W1 V2U2 W2 V2U2 W2
Filter
Figure 3-12Connecting diagram for line filters for 5 kW and 10 kW UE modules
28 kW UE refer to Fig. 3-13
3.5.5 Installation and connection regulations
