Figure 7-1
Note
When using non–PELV circuits connected to terminals AS1, AS2, the connec-
tor must be prevented from being incorrectly inserted using plug coding.
Order No. of the coding, refer to Catalog NC 60.1.
Closed–loop feed
control with user–
friendly interface
7.1 Feed control with user–friendly interface and analog setpoint interface
