Siemens SIMOTICS S-1FK2 Series User Manual

1FK2 synchronous motors for SINAMICS S120
Configuration Manual, 06/2019, A5E46927724B AB
111
Assembly drawings/dimension sheets
9
9.1
Dimension drawing 1FK2x03 and 1FK2x04
The motor has the following dimensions in the following shaft heights:
①
Example for degree of protection IP65 (with shaft sealing ring), for plain shaft and shaft with
feather key available, not for shaft extension 11(k6) x 23
②
Example for shaft extension with feather key, available for degrees of protection IP64 and IP65
Motor
Flange width
Diameter of
the circle of
holes
Centering
diameter
Centering
edge width
Corner
dimen-
sion/flange
diagonal
Flange
thickness
Flange bore
IP64
IP65
f / mm
e / mm
b / mm
f1 /
mm
f1 /
mm
a / mm
f2 / mm
s / mm
1FK2❑03
60
70
50(j6)
2.5
9.5
81
8
5.4
1FK2❑04
80
90
70(j6)
3
10
105
6.5
6.5
