Configuration
5.2 Configuring procedure
1FK2 synchronous motors for SINAMICS S120
Configuration Manual, 06/2019, A5E46927724B AB
51
General configuring procedure
The function description of the machine provides the basis for configuration. The
components are selected according to physical interdependencies and the selection process
is usually carried out in the following sequence of steps:
Table 5- 2 Configuring sequence
Description of the configuring activity
1. Clarify the drive type Refer to the
next chapter
2. Define the boundary conditions and incorporate them into the automation
system
3. Define the load case, calculate the maximum load torque and determine
the motor
4. Define the converter required Refer to
catalog
5. Repeat steps 3 and 4 for additional axes
6. Determine line-side power options (main switch, fuses, line filters, etc.)
7. Define other system components (e.g. braking resistors)
8. Calculate the current demand of the components for the 24 V DC power
supply - and specify the power supplies (SITOP devices, Control Supply
Modules)
9. Determine the connection system components
10. Configure the drive line-up components
11. Calculate the required cable cross sections for power supply and motor
connections
12. Inclusion of mandatory installation clearances
