Preparation for use
7.1 Transporting
1FK2 synchronous motors for SINAMICS S120
94 Configuration Manual, 06/2019, A5E46927724B AB
Lifting and transporting the motor with eyebolts
For the 1FK2☐10 motors, you can use eyebolts and a lifting beam for lifting and transporting.
Incorrect or unused lifting points
Due to incorrect or unused lifting points, the motor can fall and cause death, severe injury
and/or damage to property.
• Only lift and transport larger motors using the eyebolts screwed on to the end shields.
• Completely screw in the eyebolts and tighten by hand (approx. 8 Nm).
• Do not use bent or damaged eyebolts.
• Only use eyebolts with laminated fiber washers.
• Loads applied transversely to the plane of the eyebolts are not permitted.
Lifting eyes
