Procedure
• Enter the component number you just noted in parameter p4690.
Start the write operation: Enter p4691 = 2
Setting p4691 = 2 starts the transfer of the electronic rating plate from the CF card into the
encoder of the motor with the component number from p4690.
Procedure
• For parameter p4691, select value "Download SMI data (2)".
-> shortly afterward, the following is displayed: p4691 "SMI data downloaded and POWER ON
required (9)".
Check: Has p4691 changed to 9?
Yes No
Result The electronic rating plate was
successfully transferred to the
new encoder.
The electronic rating plate was
not transferred to the new encod‐
er.
Action Perform the next step. Based on the error list, identify
possible causes and remedies.
Errors and countermeasures can be found in the following table.
Error
Displayed feedback
values
0: Inactive
11: SMI data backup for selected component not found (electronic rating
plate not found)
12: Selected component not available or not connected
14: Format of the saved data is incompatible
15: Transfer fault during data download
17: Data backup does not match the parameterized encoder/motor
18: Data backup directory not permissible
19 Component already contains data
21: Component is not an SMI or a DQI
22: SMI data cannot be downloaded for component
Countermeasures
Resolve the cause of the feedback value displayed.
Contact SIEMENS service.
Description
2.4 Encoder replacement variants
Encoder replacement for SIMOTICS S-1FK2 and S-1FT2
Service Manual, 07/2022, A5E52211160B AA 51
