Description of the motors
2.4 Structure of the article number
1FK7 G2 synchronous motors
Operating Instructions, 05/2021, A5E50907562B AA
29
Description
Position of the article number
1
2
3
4
5
6
7
-
8
9
10
11
12
-
13
14
15
16
-
Z
6,000 rpm
K
DC-link voltage
270 V ... 330 V
2
510 V ... 720 V
7
Type of construction
IM B5 with a KTY84-130 or Pt1000 temperature sensor (see
Chapter "Thermal motor protection" (Page 33))
1
IM B5 with Pt1000 temperature sensor
4
Connector outlet direc-
tion
Connector size M23 and M40; rotatable connector
1
Encoder
With DRIVE-
CLiQ
AS24DQI
B
AM24DQI
C
IC22DQ
D
AM22DQ
F
AM16DQ
K
AM20DQ
L
R14DQ resolver
P
AS20DQI
Q
AM20DQI
R
R15DQ resolver
U
without
DRIVE-CLiQ
IC2048S/R
A
AM2048S/R, with EnDat 2.1
E
AM25EN22, with EnDat 2.2, for frame size 1FK704...1FK710
N
Resolver, multi-pole
S
Resolver, 2-pin
T
Shaft end
Fitted key and keyway
Shaft and flange
accuracy
Tolerance N
Holding
brake
None
A
With
B
Plain shaft
None
G
With
H
Vibration severity grade
Grade A
Degree of protection
IP64
0
IP65
1
IP65 with IP67 DE-flange
2
Options
1)
Mounting of SP+ planetary gearbox
J☐☐
Mounting of planetary gearbox LP+
V☐☐
Version for potentially explosive atmospheres Zone 2
M03
Version for potentially explosive atmospheres Zone 22
M39
Alternative shaft geometry
N05
Version for increased chemical resistance
N16
Reinforced brake
N24
Metal rating plate instead of adhesive label
Q31
Factory certificate
B02
Reference mark on the motor shaft
R06
Customer data on the rating plate
Y84
Connection to equalize pressure
Q20
Special paint finish for environmental conditions according to climate Group 3K4
K23
Special paint finish for environmental conditions according to climate Group 3K4,
primer and additional paint finish
K23+
X..
