3. Attach the load suspension device, e.g. chains to each of the three lifting eye bolts.
4. Set the motor down on a rm, level surface.
WARNING
Danger of severe injury due to unintentional movements of the motor
If the motor is not secured after being set down, unintentional movements of the motor can
cause serious injury.
• After the motor has been set down, secure it in position.
• Do not release the lifting devices until the motor has been secured in position.
5. Secure the motor against unintentional movement.
6. Remove the lifting eye bolts.
7. Close and seal the threads using screws that you removed for transport.
❒
Preparing for use
5.2Transportation and storage
SIMOTICS S-1FT2 synchronous motors for SINAMICS S120
Operating Instructions, 12/2023, A5E50610821B AF 63
