3. Set the motor down on a 󹪝rm, level surface.
WARNING
Danger of severe injury due to unintentional movements of the motor
If the motor is not secured after being set down, unintentional movements of the motor can
cause serious injury.
• After the motor has been set down, secure it in position.
• Do not release the lifting devices until the motor has been secured in position.
4. Secure the motor against unintentional movements.
❒
Procedure when transporting a motor with forced ventilation in the horizontal position
WARNING
Incorrect or unused attachment points
Due to incorrect or unused attachment points, the motor can fall and cause death, severe injury
and/or damage to property.
• Only lift and transport larger motors using the lifting eye bolts screwed on to the end
shields.
• Completely screw in the lifting eye bolts and tighten by hand (approx. 8Nm).
• Do not use bent or damaged lifting eye bolts.
• Only use lifting eye bolts with laminated 󹪝ber washers.
• It is not permissible to apply loads transversely to the plane of the lifting eye bolts.
1. Remove the screws from the threads into which you wish to screw the lifting eye bolts.
2. Screw the lifting eyes (lifting eye bolts) in at appropriate locations for the motor position
when it is being transported.



① Position of the lifting eye bolts
Preparing for use
5.2Transportation and storage
SIMOTICS S-1FT2 synchronous motors for SINAMICS S120
62 Operating Instructions, 12/2023, A5E50610821B AF
