1. Screw the lifting eyes (lifting eye bolts) in at appropriate locations for the motor position
when it is being transported.
① Position of the lifting eye bolts
2. Hook the crossbar into the lifting eye bolts (lifting eyes).
Figure5-2 Transporting the motor with a beam (example)
Preparing for use
5.2Transportation and storage
SIMOTICS S-1FT2 synchronous motors for SINAMICS S120
Operating Instructions, 12/2023, A5E50610821B AF 61
