Mounting, Connecting-up 05.2004
6SE7087-7CX87-2DA0 Siemens AG
3-4 Unité de Freinage / Braking Unit SIMOVERT MASTERDRIVES
475
1)
1)
35
2)
3)
Mounting hole for screw M6. Hook (suspension) for mounting on a G rail according to EN50035. Space required for cooling the unit. When using the option a space of 100 mm is required
45
135
425
90
427
Z
500
350
Dimension: mm Weight: approx. 18 kg
Frame B
55
X
Y
Z
X Y
3)
40
Air intake
Terminals
Reset -Amp. -Load -Temp. Ready
100
1)
Displays
Reset -Amp. -Load -Temp. Ready
45
10
85
Exhaust air
3)
100
2
Displays
X38
1
X38
C/L+
D/L-
PE1
PE2
H/R-
G/R+
2345
O V E R
Fig. 3-3 Dimension drawing type B
